Cost-Effective Solution Nitrogen Air Separation Unit For Large Infusion
Datos del producto:
| Lugar de origen: | PORCELANA |
| Nombre de la marca: | KERONG GAS |
| Certificación: | ISO9001, CE, ASME |
| Número de modelo: | Krn |
Pago y Envío Términos:
| Cantidad de orden mínima: | 1 PC |
|---|---|
| Precio: | negotiable |
| Detalles de empaquetado: | Caja de madera |
| Tiempo de entrega: | 8 semanas |
| Condiciones de pago: | L/C, T/T, Western Union, Moneygram |
| Capacidad de la fuente: | 1000pcs por año |
|
Información detallada |
|||
| Nombre: | Unidad de separación de aire de nitrógeno | Pureza: | 90%~ 99.9999% |
|---|---|---|---|
| Punto de rocío: | -45 ℃ o más | Material: | Acero inoxidable o acero al carbono |
| Capacidad: | 5Nm3/hr ~ 5500nm3/hr | Presión: | Ajustable |
| Resaltar: | PSA nitrogen gas generator for large infusion,cost-effective nitrogen air separation unit,industrial nitrogen generator with warranty |
||
Descripción de producto
| Attribute | Value |
|---|---|
| Name | Nitrogen Air Separation Unit |
| Purity | 90%~99.9999% |
| Dew point | -45℃ or more |
| Material | Stainless steel or carbon steel |
| Capacity | 5Nm3/hr~5500Nm3/hr |
| Pressure | Adjustable |
Our Cost-Effective Nitrogen Air Separation Unit provides a reliable, on-site supply of high-purity nitrogen (up to 99.99%) for large-scale infusion applications in pharmaceutical and chemical industries. Utilizing advanced Pressure Swing Adsorption (PSA) or membrane separation technology, it separates nitrogen from compressed air efficiently, ensuring stable pressure and consistent purity for sensitive processes. Designed with a skid-mounted, compact layout and automatic operation, it minimizes installation complexity, maintenance, and operational costs. Energy-efficient and fully automated, this nitrogen generator offers a dependable, continuous nitrogen supply, eliminating dependence on bulk deliveries or cylinders while supporting safe, high-quality production in large infusion facilities.
| Model | Nitrogen flow rate(Nm3/hr) | Purity(%) | Air need(m3/min) | Net dimensions(mm) |
|---|---|---|---|---|
| KRN159 | 7 | 99 | 0.33 | 1200*600*1900 |
| 6 | 99.5 | 0.32 | ||
| KRN219 | 15 | 99 | 0.7 | 1200*600*1900 |
- Online monitoring of oxygen purity, pressure, flow rate and dew point.
- Unqualified oxygen sound and light alarm, long time alarm automatic stop, unqualified automatic oxygen emptying.
- Air dryer and air filters automatic drainer discharge.
- Automatic warning of spare parts replacement.
- Remote control / fully automatic
- Molecular sieve automatic compaction
- Pneumatic valve switching by programmable controller automatic control
- The IPC, DCS, the specific configuration of other specific programs
