Precise Control System Nitrogen Air Separation Unit For Copper Powder
Datos del producto:
| Lugar de origen: | PORCELANA |
| Nombre de la marca: | KERONG GAS |
| Certificación: | ISO9001, CE, ASME |
| Número de modelo: | Krn |
Pago y Envío Términos:
| Cantidad de orden mínima: | 1 PC |
|---|---|
| Precio: | negotiable |
| Detalles de empaquetado: | Caja de madera |
| Tiempo de entrega: | 8 semanas |
| Condiciones de pago: | L/C, T/T, Western Union, Moneygram |
| Capacidad de la fuente: | 1000pcs por año |
|
Información detallada |
|||
| Nombre: | Unidad de separación de aire de nitrógeno | Pureza: | 90%~ 99.9999% |
|---|---|---|---|
| Punto de rocío: | -45 ℃ o más | Material: | Acero inoxidable o acero al carbono |
| Capacidad: | 5Nm3/hr ~ 5500nm3/hr | Presión: | Ajustable |
| Resaltar: | PSA nitrogen gas generator for copper powder,nitrogen air separation unit with precise control,industrial nitrogen generator for metal powder |
||
Descripción de producto
| Attribute | Value |
|---|---|
| Name | Nitrogen Air Separation Unit |
| Purity | 90%~99.9999% |
| Dew point | -45℃ or more |
| Material | Stainless steel or carbon steel |
| Capacity | 5Nm3/hr~5500Nm3/hr |
| Pressure | Adjustable |
Our Precise Control System Nitrogen Air Separation Unit is engineered to deliver high-purity nitrogen (up to 99.99%) with exacting control, ideal for copper powder production where oxidation-free environments are critical. Utilizing advanced Pressure Swing Adsorption (PSA) or membrane separation technology, it separates nitrogen from compressed air efficiently, ensuring stable pressure and purity for sensitive metallurgical processes. The integrated precise control system enables real-time monitoring and automatic adjustments, guaranteeing consistent nitrogen quality. Compact, energy-efficient, and low-maintenance, the skid-mounted unit provides reliable, on-site nitrogen supply, enhancing product quality, operational efficiency, and safety in copper powder manufacturing facilities.
| Model | Nitrogen flow rate(Nm3/hr) | Purity(%) | Air need(m3/min) | Net dimensions(mm) |
|---|---|---|---|---|
| KRN159 | 7 | 99 | 0.33 | 1200*600*1900 |
| 6 | 99.5 | 0.32 | ||
| KRN219 | 15 | 99 | 0.7 | 1200*600*1900 |
- Online monitoring of oxygen purity, pressure, flow rate and dew point.
- Unqualified oxygen sound and light alarm, long time alarm automatic stop, unqualified automatic oxygen emptying.
- Air dryer and air filters automatic drainer discharge.
- Automatic warning of spare parts replacement.
- Remote control / fully automatic
- Molecular sieve automatic compaction
- Pneumatic valve switching by programmable controller automatic control
- The IPC, DCS, the specific configuration of other specific programs
